Mounting
975-0239-01-01 4–7
This manual for use by qualified personnel only
Figure 4-5
Mounting the XW Solar Charge Controller
xantrex
Solar Charge Controller
Secure with two more screws.
Place keyhole slot
over the mounting
screw.
¼" 6 mm
