Xcruiser XDSR57FTA - Rear Panel

6
Rear Panel
1
LNB IN: Connect to satellite antenna (lf input from LNB to digital tuner)
2
RS-232:
Connect to a PC for software upgrade
3
L/R-AUDIO:
Connect to TV or audio tuner
4
100-240V~:
Power supply
5
ON/OFF:
Power switch
1 2 3
4 5
www.xcruiser.net
XDSR57FTA
