XES SYNERGIX 8850 PRINTER OPERATOR MANUAL 47
7. Technical data
This chapter provides the product and media specifications for the
XES Synergix 8850 Printer. It also provides the space
requirements for normal operation after product installation.
Product specifications
Table 5. Hardware specifications
Process speed 4.5 ips
Resolution 400 dpi
Environmental requirements Minimum: 60° F (10° C) at 20% relative humidity
Maximum: 80° F (27° C) at 80% relative humidity
Maximum elevation: 10,000 feet (3048 meters)
Weight 575 lbs (261 kg)
Dimensions Width:
As delivered - 23 inches (584 mm)
With output tray and AccXES controller installed - 62 inches (1575 mm)
Depth: 57 inches (1448 mm)
Height: 42.5 inches (1080 mm)
Audible noise 67 db @ Max.
Power consumption Typical power consumption for US 220V @ 20A:
Warm-up – 4660 watts
Standby – 1000 watts
Operating – 2100 watts
Rest - 120 watts
Heat output Warm-up: 14,500 BTU/hour
Standby mode: 4,000 BTU/hour
Print mode: 7,200 BTU/hour
Finishing Standard catch tray
Optional on-line folder
Optional Synergix Stacker
