Alto Hardware Manual
. Section 8: Control
RAM, ROM, and s Registers
61
Note that the function code is different for emulator
and
non-emulator tasks:
ESRB~
is F1=15
and
is
defined only in the emulator task, while
SRB
..
is
F1=
13
and
is defined
in
all RAM-related tasks besides
the emulator
..
(Fl=13 corresponds to
RMR~
in the emulator. In Altos without
the
3K
RAM
option,
F1=13 performs
RMR~
in
all RAM-related tasks, including the emulator.)
The register bank numbers are all reset to zero by a reset (bootstrap) operation, thereby causing the Alto
to behave the same as a standard Alto with a single
bank
of
S registers shared among all RAM-related
tasks.
8.8
Restrictions and
Caveats
1.
Both
RDRAM
and
WRTRAM
cause the microprocessor's system clock to stop for
one
cycle. This may
yield unspecified results
if
the system clock is
also
stopped for some other reason (e.g., waiting for
memory data).
As
a general rule, the system clock should
run
without hesitation during
the
microinstruction following a
RDRAM
or
WRTRAM,
except for the effect
of
the
RDRAM
or
WRTRAM
itself.
On
Alto
I,
there is an additional timing problem which manifests itself
in
some machines, for example,
in
the following microcode sequence:
MAR"FOO;
Starts memory reference
T"
FIE;
Loads the control
RAM
address register
L
..
MD,
WRTRAM;
Save
away
the high-order word in M
L"
MD;
Completes the write into the
RAM
What happens
is
that the last instruction suspends the system clock for one microinstruction,
and
some
Alto I memories cannot keep the memory data good for two microinstruction times, so a parity error may
occur. The data
is
actually stored in the
RAM
at the
end
of
the first microinstruction time, so there is
probably no error in the data even
if
a parity interrupt subsequently occurs. This "phantom" parity error
may
be
averted by the following code, which takes three more microinstruction times,
but
does
not
invoke the horrendous microcode overhead
of
parity error recording:
MAR"
FOO;
NOP;
L~MD;
T~MD;
TEMP"
L,
L"T;
T"FIE,
WRTRAM;
L<-TEMP;
Starts memory reference
Required
for· memory timing
Save
away
the low-order word
Save away the high-order word
. Loads the address register, starts
the
write.
Complete the write into the
RAM
2.
Unlike the control
RAM,
which can be addressed from 2 places, the control
ROM
gets its address only
from the
MPC
RAM.
Consequently, to read
ROM
location
x,
the instruction following the one with
F1
=
12B
(RDRAM)
must reside at location
(x
mod 1024). Therefore, you'll probably want to
put
the
"reading" code in the
RAM:
T<-ACl,
RDRAM,
:X;
X:
L"
ALLONES;
ACO~L,
...
Only
ACl[4-5]
are relevant
Here the read takes place
Note also that only
RaMO
can be read by these means. There is
no
known way to read RaMI.
3.
Some Alto Is have
been
observed not to evaluate
the
BUS=O
function correctly when reading
an
S-
register during the first microinstruction after a task switch. The same operation
in
other than the first
microinstruction causes no difficulty.
