5. Insert the imaging unit.
6. Close the front door, then insert the tray.
7. Open the rear door.
CCAAUUTTIIOONN——HHOOTT SSUURRFFAACCEE:: The inside of the printer might be hot. To reduce the risk of injury from a
hot component, allow the surface to cool before touching it.
8. Remove the jammed paper.
Note: Make sure that all paper fragments are removed.
276 Xerox
®
B305/B315 Multifunction Printer User Guide
Troubleshoot a problem
