Phaser 3100MFP/S
- 42 -
8 - PC Features
Companion Monitor
Graphical presentation
Run the application by clicking on the XEROX COMPANION
M
ONITOR icon located on your desktop or from the menu
S
TART >ALLPROGRAMS > XEROX COMPANION SUITE >
P
HASER 3100 MFP > COMPANION MONITOR.
From this screen you can monitor the information or
configure your machine from the tabs:
• D
EVICE SELECTION: Displays the list of devices
managed by the PC.
• C
OMPANION: Presents the machine screen (USB
connection only).
• C
ONSUMABLES: Displays the consumables status.
Device management
This tab shows the list of devices managed by the PC.
Selecting the current device
Only one device at a time may be connected to the PC.
The current device may be selected by clicking on the
radio button corresponding to the device.
Status of the connection
The status of the connection between the current device
and the PC is indicated by a colour. The following table
defines the possible states of the connection.
Device parameters
1 Select a device by clicking on its line in the list and
click on P
ROPERTIES to configure the scanning
parameters to be applied for this device when you
use the S
CAN TO function.
2 Select the desired scan M
ODE in the drop-down
menu.
Colour State
Yellow Connection in progress.
Green Connection established.
Red
The PC cannot connect to the device.
Check the USB connection.
