Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-76
PL 2.1 Feeder (1/3)
PL Item Part name Part Number
1. COVER FEED --
2. PLATE LOWER --
3. FOOT ASSY --
4. HOLDER LATCH CST 019E 89730
5. LATCH CST --
6. SPRING LATCH CST --
s6020-611
4
4
5
5
6
6
3
3
1
2
ST1
ST1
SM2
SM2
SM2
ST1
ST1
Front
