Xerox Phaser 6022 Service Manual

Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-51
Item Part Name Part Number
1. COVER ASSY TOP AIO (WITH 2, 4, 27) --
2. COVER EXTENSION AIO V --
3. -- --
4. COVER TOP AIO 848K90550
5. -- --
6. COVER ASSY REAR AIO LQ 604K 93720
7. BEARING BTR L 013E 38091
8. BEARING BTR R 013E 38101
9. ROLL ASSY BTR 022K 78520
10. KIT COVER REAR INNER AIO 3inLQ 604K 92590
11. -- --
12. SWITCH I/L ASSY (with 13) 676K 12440
13. HOLDER IL REAR --
14. -- --
15. COVER WINDOW TNR AIO LQ 848E 67463
16. HINGE CVR AIO --
17. KIT COVER MSI AIO LQ 604K 92600
18. COVER FRONT LOWER AIO VB --
19. -- --
20. -- --
21. COVER SIDE L AIO 848E 67452
22. -- --
23. SPRING IIT --
24. ARM IIT V --
25. HOLDER ARM L V --
26. HOLDER ARM R V --
27. TRAY EXTENSION AIO --
28. -- --
29. -- --
30. -- --
31. -- --
32. -- --
33. HOLDER ASSY ARM L (with 23-25) 019K 11690
34. HOLDER ASSY ARM R (with 23,24,26) 019K 11700
35. COVER FRONT UPPER AIO --
36. COVER FRONT INNER AIO --
37. LATCH MSI --
38. KIT COVER FRONT UPPER AIO (WITH 18, 35-37) 604K 92610
