Xerox Phaser 6022 Service Manual

Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-69
PL Item Part Name Part Number
1. DUCT FAN --
2. FAN MAIN 127E 86170
3. GUIDE HARNESS DRIVE --
4. PLATE BITZ --
5. PWB ASSY TOP TOKI 2 960K 76820
6. FFC ASSY LIGHT BIZ (J1-J23) 962K 79920
7. HARNESS ASSY TOKI (P1-P112) 962K 81970
8. PLATE ESS AIO --
9. PWBA ESS AIO 3IN1 604K 92530
10. -- --
11. GUIDE HARNESS MSI --
12. -- --
13. -- --
14. -- --
15. -- --
16. -- --
17. FRONT BRACKET USB --
18. PWB ASSY USB FRONT 960K 47000
19. HARNESS ASSY USB FRONT (P2-SP11) --
20. GUIDE HARNESS ESS --
www MK-Electronic de

Xerox Phaser 6022 Specifications

General

Max Print Resolution	1200 x 2400 dpi
Paper Capacity	150 sheets
Connectivity	USB 2.0, Ethernet, Wi-Fi
Processor Speed	525 MHz
Print Memory (Standard)	256 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Size	A4
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Print Speed	Up to 18 ppm
Media Sizes Supported	A4, A5, A6, B5
Monthly Duty Cycle	Up to 30, 000 pages
