Xerox VersaLink C600 User Manual

Probable Causes Solutions
The printer cable is disconnected. If the Status LED does not flash once after you send
a print job, check the connection between the printer
and the computer.
There is a network-connectivity issue. If the printer is connected to a network:
1 Verify that the Ethernet cable is connected to the
printer.
2 On the printer Ethernet connector, verify that the
green LED is On. If the green LED is not lighted,
reseat both ends of the Ethernet cable.
3 Examine the TCP/IP address in the
Communication section of the Configuration
Report. For more information, refer to Printing the
Configuration Report.
4 If the TCP/IP address is 0.0.0.0, the printer needs
more time to acquire an IP address from the
DHCP server. Wait 2 minutes, then print the
Configuration Report again.
5 If the TCP/IP address is unchanged, or begins
with 169, contact your network administrator.
There is a wireless network setup or connectivity
issue.
Verify that the Wireless Network Adapter is installed
and properly configured. For more information, refer
to Connecting to a Wireless Network.
PPrriinnttiinngg TTaakkeess TToooo LLoonngg
Probable Causes Solutions
The printer is set to a slower printing mode. For
example, the printer could be set to print on
Heavyweight paper.
It takes more time to print on certain types of special
paper. Ensure that the paper type is set properly in
the driver and at the printer control panel. For details,
refer to Print Speed.
The printer is in Power Saver mode. It takes time for printing to start when the printer is
exiting Power Saver mode.
The way the printer was installed on the network
could be an issue.
Determine if a print spooler or a computer sharing
the printer is buffering all print jobs and then
spooling them to the printer. Spooling can slow print
speeds. To test the speed of the printer, print some
Information Pages such as the Office Demo Page. If
the page prints at the rated speed of the printer, you
could have a network or printer installation issue. For
additional help, contact the system administrator.
150
Xerox
®
VersaLink
®
C600 Color Printer
User Guide
Troubleshooting

Xerox VersaLink C600 Specifications

General

Package depth	634 mm
Package width	580 mm
Package height	607 mm
Package weight	34000 g
Country of origin	Vietnam
Maximum resolution	1200 x 2400 DPI
Optional connectivity	Wireless LAN
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Print speed (black, normal quality, A4/US Letter)	53 ppm
Print technology	Laser
Duplex printing mode	Auto
Warm-up time (from sleep mode)	35 s
Time to first page (black, normal)	4.7 s
Time to first page (color, normal)	5.1 s
Duplex print speed (black, normal quality, A4/US Letter)	50 ppm
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)
PCL fonts	83
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	120000 pages per month
Recommended duty cycle	0 - 17000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, PCL 5e, PCL 6, PDF, PostScript 3, TIFF, XPS
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
Custom media width	76 - 216 mm
Custom media length	127 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A4
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Supported network protocols (IPv6)	IPv6
Internal memory	2048 MB
Noise level (idle)	33.5 dB
Sound pressure level (printing)	57.4 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (printing)	800 W
Power consumption (PowerSave)	0.7 W
Cables included	AC
Included cartridge capacity (CMY)	6000 pages
Included cartridge capacity (black)	10000 pages
Control type	Touch
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Linux operating systems supported	Fedora 25, RedHat EL Linux, Y, openSUSE 13.2
Other operating systems supported	HP-UX 11, IBM AIX 7.1
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Small Business Server 2003, Windows Small Business Server 2008
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
Height	443.4 mm
