CCoonnffiigguurriinngg AAiirrPPrriinntt
AirPrint
®
is a software feature that allows you to print from wired or wireless Apple iOS-based mobile
devices and Mac OS-based devices without the need to install a print driver. AirPrint-enabled printers
allow you to print directly from a Mac, an iPhone, iPad, or iPod touch. You can use AirPrint to print
from a wired device or a wireless device without using a print driver.
Note:
Not all applications support AirPrint
®
.
Wireless devices must join the same wireless network as the printer.
For AirPrint to function, both IPP and Bonjour
®
(mDNS) protocols must be enabled.
The device that submits the AirPrint job must be on the same subnet as the printer. To allow
devices to print from different subnets, configure your network to pass multicast DNS traffic
across subnets.
The Mac OS device must be Mac OS 10.10 or later.
AirPrint-enabled printers work with all models of iPad, iPhone (3GS or later), and iPod touch
(third generation or later), running the latest version of iOS.
1. At your computer, open a Web browser. In the address field, type the IP address of the printer,
then press Enter or Return.
Note: If you do not know the IP address for your printer, refer to Finding the IP Address of
Your Printer.
2. In the Embedded Web Server, click HomeConnectivity.
Note: If this feature does not appear, log in as a system administrator.
3. For Mobile Printing, click AirPrint.
4. To enable AirPrint, click the Enable toggle button.
Note: AirPrint is enabled by default when IPP and Bonjour
®
(mDNS) are both enabled.
To change the printer name, in the Name field, enter a new name.
To enter a location for the printer, in the Location field, enter the location of the printer.
To enter a physical location or address for the printer, in the Geo-Location field, enter the
geographic latitude and longitude coordinates in decimal form. For example, use coordinates
such as 45.325026, -122.766831 for a location.
5. Click OK.
6. To activate your changes, at the prompt, click Restart Now.
CCoonnffiigguurriinngg GGooooggllee CClloouudd PPrriinntt
Google Cloud Print allows you to print documents that are stored in the cloud without using a print
driver.
Before you begin:
46
Xerox
®
VersaLink
®
C600 Color Printer
User Guide
Getting Started

Other manuals for Xerox VersaLink C600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C600 and is the answer not in the manual?

Xerox VersaLink C600 Specifications

General IconGeneral
Package depth634 mm
Package width580 mm
Package height607 mm
Package weight34000 g
Country of originVietnam
Maximum resolution1200 x 2400 DPI
Optional connectivityWireless LAN
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32 °C
Sustainability certificatesENERGY STAR
Operating relative humidity (H-H)10 - 85 %
Print speed (black, normal quality, A4/US Letter)53 ppm
Print technologyLaser
Duplex printing modeAuto
Warm-up time (from sleep mode)35 s
Time to first page (black, normal)4.7 s
Time to first page (color, normal)5.1 s
Duplex print speed (black, normal quality, A4/US Letter)50 ppm
Standard interfacesEthernet, USB 3.2 Gen 1 (3.1 Gen 1)
PCL fonts83
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle120000 pages per month
Recommended duty cycle0 - 17000 pages per month
Number of PostScript fonts136
Number of print cartridges4
Page description languagesHP-GL, PCL 5e, PCL 6, PDF, PostScript 3, TIFF, XPS
Paper input typePaper tray
Total input capacity700 sheets
Total output capacity500 sheets
Total number of input trays1
Maximum number of input trays2
Multi-Purpose tray input capacity150 sheets
Custom media width76 - 216 mm
Custom media length127 - 356 mm
Duplex media weight60 - 176 g/m²
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 220 g/m²
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper sizeA4
Wi-Fi-
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Xerox PrintBack
Supported network protocols (IPv4)TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Supported network protocols (IPv6)IPv6
Internal memory2048 MB
Noise level (idle)33.5 dB
Sound pressure level (printing)57.4 dB
Current rating8 A
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)85 W
Power consumption (printing)800 W
Power consumption (PowerSave)0.7 W
Cables includedAC
Included cartridge capacity (CMY)6000 pages
Included cartridge capacity (black)10000 pages
Control typeTouch
Product colorBlue, White
Market positioningBusiness
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Linux operating systems supportedFedora 25, RedHat EL Linux, Y, openSUSE 13.2
Other operating systems supportedHP-UX 11, IBM AIX 7.1
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Small Business Server 2003, Windows Small Business Server 2008
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Weight and Dimensions IconWeight and Dimensions
Depth465.5 mm
Width427.4 mm
Height443.4 mm
