SSeettttiinngg DDeeffaauulltt PPrriinnttiinngg OOppttiioonnss ffoorr WWiinnddoowwss
When you print from any software application, the printer uses the print job settings specified in the
Printing Preferences window. You can specify your most common printing options and save them so
that you do not have to change the settings every time you print.
For example, if you want to print on both sides of the paper for most jobs, specify 2-sided printing in
Printing Preferences.
1. Navigate to the list of printers on your computer:
For Windows Server 2008 and later, click StartSettingsPrinters.
For Windows 7, click StartDevices and Printers.
For Windows 8.1 and Windows 10, right-click the Start iconControl PanelDevices and
Printers.
Note: If you are using a custom Start menu application, it can change the navigation
path to your list of printers.
2. In the list of printers, right-click the icon for your printer, then click Printing preferences.
3. In the Printing Preferenceswindow, click a tab, then select the options. To save the settings, click
OK.
Note: For more information about Windows print driver options, click the Helpbutton (?) in the
Printing Preferenceswindow.
SSeelleeccttiinngg PPrriinnttiinngg DDeeffaauullttss iinn WWiinnddoowwss ffoorr aa SShhaarreedd NNeettwwoorrkk
PPrriinntteerr
1. Navigate to the list of printers on your computer:
For Windows Server 2008 and later, click StartSettingsPrinters.
For Windows 7, click StartDevices and Printers.
For Windows 8.1 and Windows 10, right-click the Start iconControl PanelDevices and
Printers.
Note: If you are using a custom Start menu application, it can change the navigation
path to your list of printers.
2. In the list of printers, right-click the icon for your printer, then select Printer properties.
3. In the printer Properties dialog box, click the Advanced tab.
4. On the Advanced tab, click Printing Defaults.
5. Make your selections on the Print Driver tabs as needed, then click Apply.
6. To save the settings, click OK.
SSaavviinngg aa SSeett ooff CCoommmmoonnllyy UUsseedd PPrriinnttiinngg OOppttiioonnss ffoorr WWiinnddoowwss
You can define and save a set of options, so that you can apply them to future print jobs. In Xerox
®
App Gallery, you can save an app as default, so you can have app-by-app default settings for printing.
128
Xerox
®
VersaLink
®
C605 Color Multifunction Printer
User Guide
Printing

Table of Contents

Other manuals for Xerox VersaLink C605

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C605 and is the answer not in the manual?

Xerox VersaLink C605 Specifications

General IconGeneral
Print technologyLaser
Maximum resolution1200 x 2400 DPI
Booklet printing functionYes
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)53 ppm
Print speed (color, normal quality, A4/US Letter)50 ppm
Copier resize25 - 400 %
Maximum copy resolution600 x 400 DPI
Maximum number of copies999 copies
Time to first copy (black, normal)5 s
Time to first copy (color, normal)7 s
Duplex copy speed (black, US Letter)47 ppm
Copy speed (black, normal quality, A4)53 cpm
Scan toE-mail, File, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Input color depth24 bit
Maximum scan area216 x 356 mm
Output color depth8 bit
Scan speed (color)46 ppm
Image formats supportedJPG, TIF
Duplex scan speed (black)71 ppm
Duplex scan speed (color)52 ppm
Document formats supportedPDF, XPS
Optical scanning resolution600 x 600 DPI
FaxingMono faxing
Fax memory4 MB
Modem speed33.6 Kbit/s
Fax forwarding toE-mail
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)2000
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle120000 pages per month
Recommended duty cycle0 - 15000 pages per month
Page description languagesHP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Internal memory4096 MB
Card reader integratedNo
Internal storage capacity250 GB
Sound power level (standby)33.5 dB
Sound pressure level (printing)54.7 dB
Wi-Fi standardsWi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print
Supported network protocols (IPv4)TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD, LDAP, FTP
Standard interfacesUSB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity1
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (sleep)0.9 W
Power consumption (standby)90 W
Power consumption (printing)820 W
Power consumption (average operating)- W
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)15 - 85 °C
Operating relative humidity (H-H)10 - 32 %
Package depth655 mm
Package width594 mm
Package height789 mm
Package weight44000 g
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Paper input typePaper tray
Total input capacity550 sheets
Total output capacity400 sheets
Maximum input capacity3250 sheets
Auto document feeder (ADF) input capacity100 sheets
Custom media width76 - 190 mm
Custom media length216 - 356 mm
Duplex media weight60 - 128 g/m²
Paper tray media typesCard stock, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 220 g/m²
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead
Maximum ISO A-series paper sizeA4
Sustainability certificatesENERGY STAR
Market positioningBusiness
Weight and Dimensions IconWeight and Dimensions
Depth503 mm
Width470 mm
Height643.7 mm
