Page #149 background imageLoading...
Page #149 background image
Using Special Pages
The Special Pages options control how covers, inserts, and exception pages are added to your printed
document.
For Windows, the Special Pages tab is on the Document Options tab.
For Macintosh, in the Print window, in Xerox Features, Special Pages is in the Paper field for Paper/
Output.
Printing Cover Pages
A cover page is the first or last page of a document. You can select paper sources for the cover pages
that are different from the source used for the body of a document. For example, you can use your
company letterhead for the first page of a document. You can also use heavyweight paper for the
first and last pages of a report. You can use any applicable paper tray as the source for printing cover
pages.
Select one of these options for printing cover pages:
No Covers: This option does not print cover pages. No cover pages are added to the document.
Front Only: This option prints the first page on paper from the specified tray.
Back Only: This option prints the back page on paper from the specified tray.
Front and Back: Same prints the front and back cover pages from the same tray.
Front and Back: Different prints the front and back cover pages from different trays.
After making a selection for printing the cover pages, you can select the paper for the front and back
covers by size, color, or type. You can also use blank or pre-printed paper, and you can print side one,
side two, or both sides of the cover pages.
Printing Insert Pages
You can add blank or pre-printed insert pages before page one of each document or after designated
pages within a document. Adding an insert after designated pages within a document separates
sections, or acts as a marker or placeholder. Ensure that you specify the paper to use for the insert
pages.
Insert Options provides the options to place an insert After Page X, where X is the specified page,
or Before Page 1.
Insert Quantity specifies the number of pages to insert at each location.
Pages: Specifies the page or range of pages that use the exception page characteristics. Separate
individual pages or page ranges with commas. Specify pages within a range with a hyphen. For
example, to specify pages 1, 6, 9, 10, and 11, type 1,6,9-11.
Paper: Displays the default size, color, and type of paper selected in Use Job Settings.
Job Setting: Displays the attributes of the paper for the remainder of the job.
Printing Exception Pages
Exception pages have different settings from the rest of the pages in the job. You can specify
differences such as page size, page type, and page color. You can also change the side of the paper
on which to print as your job requires. A print job can contain multiple exceptions.
149

Table of Contents

Other manuals for Xerox VersaLink C7125

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C7125 and is the answer not in the manual?

Xerox VersaLink C7125 Specifications

General IconGeneral
N-up printing2, 4, 6, 8, 9, 16
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 2400 DPI
Time to first page (black, normal)6.7 s
Time to first page (color, normal)8.8 s
Print speed (black, normal quality, A3)14 ppm
Print margins (top, bottom, right, left)4 mm
Print speed (black, normal quality, A4/US Letter)25 ppm
Optional connectivityBluetooth, Wireless LAN
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Mopria Print Service
Supported network protocols (IPv4)TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour /AirPrint
Processor cores2
Sound power level (standby)41 dB
Sound power level (printing)65 dB
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (sleep)0.4 W
Power consumption (standby)94 W
Power consumption (printing)400 W
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
Time to first copy (black, normal)5.7 s
Time to first copy (color, normal)8.1 s
Copy speed (black, normal quality, A4)25 cpm
DisplayLCD
Control typeTouch
Product colorBlue, White
Display diagonal7 \
Market positioningBusiness
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supportedHP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2
Windows operating systems supportedWindows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan toE-mail, Network folder, SMB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Maximum scan area297 x 431.8 mm
Output color depth24 bit
Output grayscale depth8 bit
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Included cartridge capacity (CMY)9800 pages
Included cartridge capacity (black)16100 pages
PCL fonts83
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Duplex functionsCopy, Print, Scan
Maximum duty cycle107000 pages per month
Recommended duty cycle0 - 6250 pages per month
Number of PostScript fonts136
Number of print cartridges4
Page description languagesHP-GL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF
Total input capacity620 sheets
Total output capacity250 sheets
Paper tray 1 input capacity520 sheets
Multi-Purpose tray input capacity100 sheets
Auto document feeder (ADF) input capacity130 sheets
Custom media width88.9 - 297 mm
Custom media length98.4 - 431.8 mm
Paper tray media typesBond paper, Card stock, Heavy printing media, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 256 g/m²
ISO A-series sizes (A0...A9)A3, A4
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA3
Auto Document Feeder (ADF) media weight38 - 128 g/m²
HDD capacity320 GB
Browser supportedMicrosoft Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth670.8 mm
Width590 mm
Height766.5 mm
