11. Return lever 2f to its original position.
12. To close the transfer drawer, grasp handle 2 and gently push in the drawer completely
; turn the green handle to the left to lock the drawer in place .
13. Close the left and center front doors completely. The press does not operate when
doors or covers are open.
Clearing Jams in Areas 3, 4 and 5
Important
Before opening any press doors, ensure that the press has stopped printing.
1. Open the right front door.
Xerox
®
Versant
®
3100 Press5-4
Quick Start Guide
Troubleshooting
