Detailed Specifications WorkCentre
®
7970 Series
Customer Expectation and Installation Guide 4
Foreign Device Interface (FDI) (Optional)- Also known as
Auxiliary Access Device, this is an interface to third party access
control devices, such as coin machines and card readers.
Operating Environment
Required Temperature
Range
50° to 82° F (10° to 28° C)
Required Relative Humidity
Altitude (above sea level)
Max of 8,200 Feet (2,500 meters)
Sound Power Levels (Base
config)
Sound Pressure Levels
(Base config)
Electrical Requirements
Geographies: Western Hemisphere:
Voltage : 110-127
VAC +/- 10%
Frequency: 50/60 Hz
+/- 3%, 20 A
Voltage : 110-127 VAC +/-
10%
Frequency: 50/60 Hz +/- 3%,
15A
Geographies: Eastern Hemisphere :
Europe / Asia / South America / Africa
Voltage : 220-240
VAC +/- 10%
Frequency: 50/60 Hz
+/- 3%, 10 A
Voltage : 220-240 VAC +/-
10%
Frequency: 50/60 Hz +/- 3%,
10 A
Requires use of a 10 ampere outlet which is standard
in most modern office buildings. Consult with local
service to determine the country specific receptacle
and confirm the existence of this outlet in the proposed
installation space.
The first print and copy out times were measured with machine in
ready condition, image quality setting at defaults,
Reduction/Enlargement at 100%, uncollated, selecting and feeding a
8.5x11 LEF / A4 LEF plain paper sheet from tray 1 in black or full color
respectively and feeding to the bottom center tray without any finisher
installed. Priority mode set to color or black and white as appropriate.
The first copy out time (FCOT) is measured from when the Start
button is pressed to when the trail edge of the first copy is output to the
specified destination.
Electrical Requirements
(Default time to
Sleep mode = 2
min.)
(Default time to
Sleep mode = 2
min.)
Feature Specifications
As fast as 6.9 sec / 4.2 sec.
Printing registration specifications for 8.5 x 11”
(A4):
Tray 1-4: ±1.5 mm (side 1), ±1.9 mm (side 2)
along the lead edge and ±2.0mm (side 1),
±2.4mm (side 2) mm along the side edge
Bypass Tray: Lead Edge is ±2.2 mm and Side
edge ±3.0 mm
Skew registration specification from side-to-side
feeding for 8.5 x 11” (A4)
Tray 1-4 is ±3 mm (side 1), ±4 mm (side 2)
Bypass tray skew is ±4 mm.
The product will reproduce 11”x17” full bleed image
when printing on 12”x18” paper and A3 full bleed
when printing on SRA3 paper. The maximum
length images (476.6mm) are only produced on
media 19” long. On all media there is a Lead Edge
deletion of 4mm and a Trail Edge deletion of 2mm.
The Side Edge deletion varies with paper size. For
paper less than 12” wide the Side Edge deletion is
2mm per edge. For widths greater than 12” the
Side Edge deletion is determined by the paper
width less the imageable area divided by 2.
Print:
Max. Image Area: 305mm x 476.6mm / 12” x
18.76”
Guaranteed Image Quality Area : 297mm x
476.6mm /11.69” x 18.76”
Copy:
Max. Image Area: 297mm x 432mm / 11.69” x
17”
The first print out time (FPOT) is the duration from the Print Job
request to the delivery into the output tray. Overall system print
performance (‘Click to Clunk’ time) is primarily dependent upon the
software applications and network environment being used.
Rasterizing (RIP-ing) is only a small fraction of Click to Clunk time.
