WorkCentre 7220-7225 Information Assurance Disclosure Paper
Ver. 1.0, January 2013 Page 57 of 61
RFC 3805 - Printer MIB Group WorkCentre/ColorQube
General group [
]
Covers group [
]
Localization group [
]
caveats = only US English language supported
Responsible Party group [2 objects] - OPTIONAL
System Resources group [
]
Input group [
]
Extended Input group [7 objects] - OPTIONAL
Input Media group [4 objects] - OPTIONAL
Output group [
]
supported w/ caveats = only "
3" (i.e. can accept 1 or more sheets) can
be supported for the Top Tray (C)
Extended Output group [7 objects] - OPTIONAL
Output Dimensions group [5 objects] OPTIONAL
Output Features group [6 objects] - OPTIONAL
Marker group [
]
Marker Supplies group [9 objects] - OPTIONAL
Marker Colorant group [5 objects] - OPTIONAL
Media Path group [
]
Channels group [
]
Interpreter group [
]
Console group [
]
supported w/ caveats = prtConsoleDisable is hardcoded to enabled(3),
prtConsoleLocalization hardcoded to 1
Console Display Buffer group [
]
supported w/ caveats = limited local UI messaging captured within table
(C), local UI button selection messages are not captured within table
Console Display Light group [
]
supported w/ caveats = only the Power Saver LED is suppo
LEDs were not implemented because they represent local UI menu
activations (I)
Alert Table group [8
]
Alert Time group [1 object] - OPTIONAL
RFC 2790 – Host Resources MIB group WorkCentre/ColorQube
System group [
]
Storage group [
]
Devices group [
]
Processor Table [
]
Network Interface Table [
]
Printer Table [
]
Disk Storage Table [
]
Partition Table [
]
File System Table [
]
Software Running group [7 objects] – OPTIONAL
Software Running Performance group [2 objects] – OPTIONAL
Software Installed group [7 objects] – OPTIONAL
RFC 1213 - MIB-II for TCP/IP group WorkCentre/ColorQube
System group [
]
Interfaces group [
]
supported w/ caveats = ifInUnknownProtos does not work
Address Translation group [
]
supported, but this group has been DEPRICATED by the IETF
IP group [
]
ICMP group [
]
TCP group [
]
UDP group [
]
EGP group [
]
cause Exterior Gateway Protocol not supported by
machine
Transmission group [
]
not applicable because the group has not yet been defined by the IETF
SNMP group [
]
System Object Resources Table/objects per RFC 1907 [
objects]
