Xerox WorkCentre 7545 User Manual

Troubleshooting
WorkCentre 7500 Series Multifunction Printer 239
User Guide
CAUTION: Some paper and other media types can cause poor output quality, increased paper jams,
or damage your printer. Do not use the following:
 Rough or porous paper.
 Inkjet paper.
 Non-laser glossy or coated paper.
 Paper that has been photocopied.
 Paper that has been folded or wrinkled.
 Paper with cutouts or perforations.
 Stapled paper.
 Envelopes with windows, metal clasps, side seams, or adhesives with release strips.
 Padded envelopes.
 Plastic media.
 Make sure the paper type selected in your print driver matches the paper type on which you are
printing.
 If you have the same size paper loaded in more than one of the trays, make sure that the proper tray
is selected in the print driver.
 Store your paper and other media properly for optimum print quality. For details, see Paper Storage
Guidelines on page 39.
Print-Quality Modes
Select the correct Print-Quality Mode for your print job from the print driver. For instructions on setting
the Print-Quality Mode, see Selecting Printing Options on page 59. To control the Print-Quality Mode:
 Make sure that the Print-Quality Mode is set to the correct mode. For example, if the print appears
too light, make sure the Print-Quality Mode is not set to Toner Saver mode. The default setting is
Standard.
 Use the Print-Quality Mode settings in the print driver to control print quality. If the print quality is
not suitable, adjust the Print-Quality Mode setting to a higher level.
 Use only Xerox
®
supported paper types and sizes. For details, see Supported Paper on page 38.
Color Corrections and Color Adjustments
Color Correction is set to Automatic at the factory for best printing results of mixed text, graphics, and
images on a range of supported paper. For instructions on setting the Color Correction, see Using Color
Corrections on page 65. Follow these guidelines to control the Color Corrections and Color Adjustments:
 Make sure that the Color Correction in the print driver is set to Automatic for best results on most
paper.
 Select a mode of Color Correction to produce more vivid results. For example, when printing graphics
in which the sky does not look blue enough, select Vivid for more vibrant blue skies.
 Select a Custom Color Adjustment, such as Office Color, Press Match, or Spot Color, to match the
color output to another output device.

Xerox WorkCentre 7545 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Print speed (black, normal quality, A4/US Letter)	45 ppm
Languages support	CZE, DAN, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUM, RUS, SWE, TUR
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	1064 x 685 x 1127 mm
Printer management	SNMP, MIB
Networking features	Gigabit Ethernet
All-in-one functions	Copy, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, print, scan
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	200000 pages per month
Optional functions	Fax
Number of print cartridges	4
Page description languages	HP-GL/2, Microsoft XPS, PCL 5c, PCL 6, PostScript 3, TIFF
Copier resize	25 - 400 %
Maximum number of copies	9999 copies
Time to first copy (black, normal)	6.6 s
Time to first copy (color, normal)	7.8 s
Copy speed (black, normal quality, A4)	45 cpm
Scan to	E-mail, FTP, USB
Input color depth	24 bit
Maximum scan area	A3 (297 x 420) mm
Scan speed (color)	70 ppm
Image formats supported	JPG, TIF
Optical scanning resolution	600 x 600 DPI
Paper input type	Paper tray
Total input capacity	620 sheets
Total output capacity	1120 sheets
Maximum input capacity	5140 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	110 sheets
Envelopes sizes	C5, DL
Custom media width	140 - 297 mm
Maximum print size	297 x 420 mm
Custom media length	182 - 432 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Plain paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Display	-
Control type	Touch
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Authentication method	NDS/LDAP/Kerberos/SMB
Internal memory	3072 MB
Internal storage capacity	160 GB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	18 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	9.1 W
Power consumption (standby)	130 W
Power consumption (PowerSave)	82 W
Power consumption (average operating)	984 W
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Linux operating systems supported	Fedora 7, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, Solaris 10 U4, Solaris 10 U5, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Certification	FCC, ICES, TUV, CB, GOST, NOM, CE, EAL3
