XFX nForce 790i Ultra User Manual

XFX nForce 790i Ultra 3-Way SLI Motherboard
4
2-Port SATA Power Cable (Qty Three)
1394 Cable
Provides two additional 1394 ports to either
the front or back panels of the chassis.
USB 2.0 4-Port Cable
Provides four additional USB ports to either
the front or back panels of the chassis.
SATA Signal Cable (Qty Six)
Used to support the Serial ATA protocol and
each one connects a single drive to the
motherboard
IDE-ATA 133 HDD Cable
SLI Bridge (use for two graphics cards in SLI)
3-Way SLI Bridge (use for three graphics
cards in SLI)
XFX nForce 790i Ultra SLI
Motherboard
The XFX nForce 790i Ultra SLI motherboard with the NVIDIA nForce 790i
Ultra SLI SPP and MCP processors is a PCI Express, SLI-ready motherboard.
Figure 1 shows the motherboard and Figures 2 shows the back panel
connectors.
