Hardware Installation

There are three more fan connectors on the motherboard. For this installation,

these will not be used.

COM1

The motherboard kit provides an additional serial COM header for your

machine. Connect one side of a switching cable to the header and then attach

the serial COM device to the other side of the cable.

System fan

connector

Chassis fan

connector

Auxiliary fan

connector

Fan Connector

3 2

GND

+12V

SENSE
