Configuring the BIOS
43
CPUOC 4%
CPUOC 5%
CPUOC MAX
When you select one of the CPUOC x% options, the FSB - Memory
Clock Mode is set to Unlinked and cannot be changed until SLI-
Ready Memory is set to Disable.
FSB and Memory Clock Mode
Use the Page Up and Page Down keys to scroll through the FSB and
Memory Clock Mode options. The options are:
Auto
This is the optimal setting since it sets the FSB and memory speeds
automatically.
Linked
When Link is selected, FSB (QDR), MHz is changed to editable and
the FSB speed can be entered manually. As the FSB speed is changed,
CPU Freq, MHz changes proportionally.
Unlinked
When Unlink is selected,
FSB (QDR), MHz and MEM (DDR), MHz
are changed to editable and the FSB and memory speeds can be entered
manually. As the FSB speed is changed, CPU Freq, MHz changes
proportionally.
FSB – Memory Clock Mode [Linked]
FSB (QDR), MHz [1067] 1066.7
Actual FSB (QDR), MHz 1066.7
MEM (DDR), MHz [1067] 800.6
Actual MEM (DDR), MHz 800.0
CPU Freq, MHz 2933.3 2933.3
CPU Multiplier 11X 11X
FSB – Memory Clock Mode [Linked]
FSB (QDR), MHz [1067] 1066.7
Actual FSB (QDR), MHz 1066.7
x MEM (DDR), MHz Auto 800.6
Actual MEM (DDR), MHz 800.0
