XFX nForce 790i Ultra User Manual

Configuring the BIOS
49
 nForce SPP
This function defines the core voltage level for the NVIDIA nForce SPP
chip. Use the Page Up and Page Down keys to select a voltage (1.20V, 1.30V,
1.40V, 1.50V) or select [Auto]to automatically set the voltage.
 nForce MCP
This function defines the core voltage level for the NVIDIA nForce MCP
chip. Use the
Page Up and Page Down keys to select a voltage or select
[Auto]to automatically set the voltage.
 HT nForce SPP <-> MCP
This function defines the voltage level for the NVIDIA HT nForce SPP <->
MCP Link. Use the Page Up and Page Down keys to select a voltage or select
[Auto]to automatically set the voltage.
 nForce MCP Auxiliary
This function defines the core voltage level for the NVIDIA nForce MCP
Auxiliary voltage. Use the Page Up and Page Down keys to select a voltage or
select [Auto]to automatically set the voltage.
 GTLVREF Lane 0
This function defines the voltage level for GTLVREF Lane 0. Use the Page
Up and Page Down keys to select a voltage or select [Auto]to automatically
set the voltage.
 GTLVREF Lane 1
This function defines the voltage level for GTLVREF Lane 1. Use the Page
Up and Page Down keys to select a voltage or select [Auto]to automatically
set the voltage.
 GTLVREF Lane 2
This function defines the voltage level for GTLVREF Lane 2. Use the
Page
Up and Page Down keys to select a voltage or select [Auto]to automatically
set the voltage.
 GTLVREF Lane 3
This function defines the voltage level for GTLVREF Lane 3. Use the Page
Up and Page Down keys to select a voltage or select [Auto]to automatically
set the voltage.
