Xhorse KEY TOOL PLUS - Ports and accessories

Synchronization：Users can synchronize tokens and collect bonus points. See
Fig. 4.1.8
Update notification bar: The update information of the device.
Serial number: The serial number of the device.
Fig.4.1.8
4.2.1 Name of device ports
Fig. 4.2.1 Front View
4.2 Ports and accessories
3
4
1
2
5
9
6
7 8
7
① Screen
② Light sensor----detect the brightness in the current environment
③ Detection coil (including 125K low, 13.56M Medium, 300-900M high frequency)
-----Support reading, writing and cloning common immo transponder
-----Support reading common ID transponders
-----Support reading common IC transponders
-----Support frequency detection of common vehicle remotes
④ Immo transponder placement hole----for vehicle immo transponders
⑤ Screw hole for tablet support
(Optional accessory)
⑥ Hand strap holder
⑦ Speaker
⑧ Microphone
⑨ Camera & flashlight
Fig. 4.2.2 Back View
More
KEY TOOL PLUS Overview
9 10
KEY TOOL PLUS Overview
