If the card was installed correctly, you will see a high-level summary of the tests performed
similar to the following output. If the output is not similar to the one shown below, see Chapter
7: Troubleshoong.
INFO: Found 1 cards
INFO: Validating card[1]: xilinx_u250_gen3x16_xdma_shell_3_1
INFO: == Starting Kernel version check:
INFO: == Kernel version check PASSED
INFO: == Starting AUX power connector check:
INFO: == AUX power connector check PASSED
INFO: == Starting Power warning check:
INFO: == Power warning check PASSED
INFO: == Starting PCIE link check:
INFO: == PCIE link check PASSED
INFO: == Starting SC firmware version check:
INFO: == SC firmware version check PASSED
INFO: == Starting verify kernel test:
INFO: == verify kernel test PASSED
INFO: == Starting DMA test:
Host -> PCIe -> FPGA write bandwidth = 9066.781182 MB/s
Host <- PCIe <- FPGA read bandwidth = 11837.876581 MB/s
INFO: == DMA test PASSED
INFO: == Starting device memory bandwidth test:
............
Maximum throughput: 52077 MB/s
INFO: == device memory bandwidth test PASSED
INFO: == Starting PCIE peer-to-peer test:
P2P BAR is not enabled. Skipping validation
INFO: == PCIE peer-to-peer test SKIPPED
INFO: == Starting memory-to-memory DMA test:
bank0 -> bank1 M2M bandwidth: 12426 MB/s
bank0 -> bank2 M2M bandwidth: 12392.3 MB/s
bank0 -> bank3 M2M bandwidth: 11347 MB/s
bank1 -> bank2 M2M bandwidth: 12424.8 MB/s
bank1 -> bank3 M2M bandwidth: 12231.8 MB/s
bank2 -> bank3 M2M bandwidth: 12412.1 MB/s
INFO: == memory-to-memory DMA test PASSED
INFO: == Starting host memory bandwidth test:
Host_mem is not available. Skipping validation
INFO: == host memory bandwidth test SKIPPED
INFO: Card[0] validated successfully.
INFO: All cards validated successfully.
Note: The DMA bandwidth can vary depending upon NUMA/CPU anity.
If the shell paron has not been programmed to the card, the output will look similar to the following.
Ensure to program the shell as described above.
INFO: Found 1 cards
INFO: Validating card[0]: xilinx_u250_gen3x16_base_3
INFO: == Starting Kernel version check:
INFO: == Kernel version check PASSED
INFO: == Starting AUX power connector check:
INFO: == AUX power connector check PASSED
INFO: == Starting Power warning check:
INFO: == Power warning check PASSED
INFO: == Starting PCIE link check:
