Xilinx KC705 Getting Started

6 www.xilinx.com KC705 Getting Started Guide
UG913 (v1.0.1) May 31, 2012
Chapter 1: Getting Started with the Kintex-7 FPGA KC705 Embedded Kit
• Reference designs and demonstrations:
• BIST - MicroBlaze processor subsystem
• Web server-based multi video streams demonstration system
• Reference designs, demonstrations, documentation, and applications delivered on
USB flash drive to get started quickly
What’s Available Online
• License for ISE Design Suite: Embedded Edition:
• http://www.xilinx.com/support/licensing_solution_center.htm
• http://www.xilinx.com/tools/faq.htm
• Embedded kit home page with documentation and reference designs:
• http://www.xilinx.com/products/boards-and-kits/EK-K7-KC705-G.htm
• Technical support:
• http://www.xilinx.com/support
Getting Started with the Video Demonstration
This Kintex-7 FPGA embedded kit comes with a video demonstration available on the
provided USB flash drive. This demonstration can be run before installing any additional
tools to get an overview of the features of the KC705 evaluation board using a MicroBlaze
processor subsystem in the Kintex-7 (XC7K325T-FF900-2) FPGA.
Processor System Used for the Video Demonstration
The provided video demonstration uses a pre-built Kintex-7 FPGA design (Figure 1-1)
with these features:
• MicroBlaze processor
• External DDR3 SDRAM interface
• External flash memory interface
• On-chip memory (block RAM)
• Integrated Tri-Mode Ethernet MAC
• UART (connected from the KC705 board via the USB-UART connector)
• Interrupt controller (Intc) and timer
• GPIO (LCD, LEDs, buttons, switches, and rotary)
• Software-configurable XADC block
