Page #10 background imageLoading...
Page #10 background image
USB3.0
There are four USB3.0 interface ports available on the KV260 Starter Kit carrier card. Each port
can deliver a 5V supply to the aached I/O peripherals with up to 900 mA per port. All ports are
protected against an over-current event through individual 900 mA power switches per port.
Note: The total current (across all four ports) is allocated at 2.1A.
Pmod Connector
The Pmod interface (from Digilent Inc.) is supported by the 3.3V, 100 mA capacity on the supply
pin.
Raspberry Pi Camera Interface
The Raspberry Pi camera 15 pin interface connector is supported by the 3.3V supply voltage on
the supply pin.
IAS Module Connector
The SOM supports two IAS module connectors, as dened by the ON Semiconductor IAS
module denion standard. The KV260 Starter Kit carrier card provides 2.75V, 1.8V, and 1.2V
supply rails on specied power pins.
Fan and Heat Sink
The KV260 Starter Kit is built with an integrated acve cooling soluon (see Figure 2). The
integrated fansink allows you to exercise the full 10W Zynq
®
UltraScale+™ MPSoC applicaon
power budget without any addional accessories.
Out of the box, the 12V fan should already be plugged into the starter kit. If it is not, be sure that
the fan is plugged into the connector designated in Table 2. The fan connector is keyed to ensure
proper orientaon.
By default, the fan runs at a constant speed. Variable fan speed control can be implemented
through a FPGA based PWM fan controller. The fan gang signal is connected to a FPGA HD I/O
bank pin for control. Consult the corresponding KV260 Starter Kit carrier card schemac for
specic pin assignment and Xilinx SOM source code repositories for an RTL implementaon that
can be integrated with your design.
Chapter 2: Initial Setup
UG1089 (v1.2) July 26, 2022 www.xilinx.com
KV260 Starter Kit 10
