16 www.xilinx.com ML605 Hardware User Guide
UG534 (v1.2.1) January 21, 2010
Chapter 1: ML605 Evaluation Board
A15 DDR3_A6 90 A6
B15 DDR3_A7 86 A7
G15 DDR3_A8 89 A8
F15 DDR3_A9 85 A9
M16 DDR3_A10 107 A10/AP
M15 DDR3_A11 84 A11
H15 DDR3_A12 83 A12_BC_N
J15 DDR3_A13 119 A13
D15 DDR3_A14 80 A14
C15 DDR3_A15 78 A15
K19 DDR3_BA0 109 BA0
J19 DDR3_BA1 108 BA1
L15 DDR3_BA2 79 BA2
J11 DDR3_D0 5 DQ0
E13 DDR3_D1 7 DQ1
F13 DDR3_D2 15 DQ2
K11 DDR3_D3 17 DQ3
L11 DDR3_D4 4 DQ4
K13 DDR3_D5 6 DQ5
K12 DDR3_D6 16 DQ6
D11 DDR3_D7 18 DQ7
M13 DDR3_D8 21 DQ8
J14 DDR3_D9 23 DQ9
B13 DDR3_D10 33 DQ10
B12 DDR3_D11 35 DQ11
G10 DDR3_D12 22 DQ12
M11 DDR3_D13 24 DQ13
C12 DDR3_D14 34 DQ14
A11 DDR3_D15 36 DQ15
G11 DDR3_D16 39 DQ16
F11 DDR3_D17 41 DQ17
D14 DDR3_D18 51 DQ18
C14 DDR3_D19 53 DQ19
Table 1-4: DDR3 SODIMM Connections (Cont’d)
U1 FPGA Pin Schematic Net Name
J1 SODIMM
Pin Number Pin Name
