Mode Switch Setup
Set SW11 to 00010 (1 = on, Position 1 Position 5, left to right)
This enables Master BPI configuration from the Linear Flash
Flash A25, A24 = 00
FPGA mode pins M[2:0] = 010
Note: Presentation applies to the VC707
