Xinje DS5F-21P5-PTA User Manual

28
 130 series motor installation dimensions Unit: mm
a130
145
4-
9
LA
2
5
LB
57±0.5
40
2.5
22h6
110h7
18.5
0
-0.1
6
0
-0.02
M6深15
Motor model
LA±1
LB
Inertia level
Normal
With
brake
MS5G-130STE-C□05415□□-20P8-S01
117.5
147.0
12.5
Middle inertia
MS5G-130STE-C□06025B-21P5-S01
122
-
MS5G-130STE-C□07220□□-21P5-S01
132.5
162.5
MS5G-130STE-C□10015B-21P5-S01
145
-
MS5G-130STE-C□11515□□-21P8-S01
159.5
189.5
MS5G-130STE-C□11515□□-41P8-S01
MS5G-130STE-C□14615□□-22P3-S01
180.5
210.5
MS5G-130STE-C□14615□□-42P3-S01
MS5G-130STE-TL05415□□-20P8-S01
134.5
164.5
MS5G-130STE-TL07220□□-21P5-S01
149.5
179.5
MS5G-130STE-TL11515□□-21P8-S01
176.5
206.5
MS5G-130STE-TL11515□□-41P8-S01
MS5G-130STE-TL14615□□-22P3-S01
197.5
227.5
MS5G-130STE-TL14615□□-42P3-S01
MS-130ST-T04030B-21P2
164
223
14
-
MS-130ST-T06025□□-21P5
179
238
MS-130ST-T10015□□-21P5
205
264
MS-130STE-T07730□□-22P4
205
264
MS-130ST-T15015G□□-22P3
235
294
MS-130ST-TL10025□□-22P6
209
290
MS-130ST-TL10030□□-43P0
225
284
