XO FLEX – Installation instructions Installation requirements
7
• Air pressure 5.5 – 7.5 bar
• Air flow rate > 55 l/min
• Humidity dew point < -20°C at atmospheric pressure
• Oil contamination max. 0.5 mg/m
3
• Particulate contamination < 100 particles/m
3
(particle size 1 –
5 µm)
If the incoming air pressure exceeds 7.5 bar, a reduction valve
must be fitted.
Air quality must be in accordance with local air regulations.
Pipe 3/8” female internal thread – preferably fitted with a ball
valve – see YB-235.
Incoming water:
• Inlet pressure 2.5 – 6 bar
• Water flow rate > 5 l/min
• pH: 6.5 – 8.5
• Maximum particle size < 100 µm
If the incoming water pressure exceeds 6 bar, a reduction valve
must be mounted in front of the unit.
Water quality must be in accordance with local drinking water
regulations.
Maximum inlet water conductivity:
850 µS/m
softener filter
cartridge (UH-200).
o
dH
Filter replacement interval
Every 12 months (part of preventive service)
If the unit is not supplied with “unit backflow water prevention”, it
must have an external backflow prevention device at the
connection point with the water supply, or an air gab of at least 20
mm.
Plastic pipe Ø 32 mm with socket – see YB-235.
Gradient of waste water lines > 1%
Drainage capacity > 10 l/min
To avoid the risk of electric shock, this equipment must be connected to supply
mains with protective earth.
To avoid the risk of electric shock, always switch off the power to the unit in the
electrical panel before opening or touching the internal components.
When connecting an external PC to the unit, the external PC must be powered by a
medical grade isolating transformer!
Equipment connected to USB and RS-232 connections, must conform with IEC
60950-1.
