XO FLEX – Installation instructions Checking the unit
48
11. Place a cup in the cup holder and test the cup filler.
12. Test the cuspidor flush.
13. Test both suction hoses.
14. Test instrument suspension individually, assess power and mechanical function.
15. Test the foot control.
a. Patient chair up/down
b. Patient chair backrest inclination
c. For all instruments test:
i. Start/stop using the pedal
ii. Adjustment of maximum speed/power using the joystick
iii. Adjustment of spray water/irrigation setting using the joystick
16. Test the chair base joystick (all chair programs).
17. Test the operating light using the no-touch sensor:
a. On/off
b. Three light intensities
18. If installed, test the assistant call function.
19. If installed, test that the XO HD Display is functioning correctly.
20. If installed, test the XO Suction Disinfection system.
21. If installed, test the XO Water Disinfection system.
22. Check the unit for leakages:
a. Water
b. Air
c. Suction
d. Drain
6.3 FINALIZING THE INSTALLATION
1. Set the hour and date.
2. Set the date of the first preventive service and safety inspection – 12 months from today.
3. Fit the unit stand panels.
4. Move the patient chair up and down and check the clearance between the panels.
5. Check the unit for scratches or other handling damage.
6.4 ADJUSTING THE UNIT
ADJUSTING THE AIR INSTRUMENT (TURBINE), DRIVE AIR AND COOLING AIR OF THE MICROMOTOR
Table 4 – Adjustment of air instrument drive air
Check/adjust drive air pressure
Action
Display
Fit the test manometer (FA-041)
and a turbine to the air instrument
coupling.
Switch the unit on.
Lift the air instrument hose
forward.
Speed % of maximum
Check the maximum drive air
pressure.
Activate the configuration button
under the bridge twice within one
second (see
Figure 66).
DA MAX
