XO CARE A/S
YB-223 Version 3.00 XO Osseo, User Guide 23
J. TECHNICAL SPECIFICATIONS
Speed range: 15-2000 rpm with 20:1 reduction handpiece.
Max. driving torque: At least 45 Ncm with MM 20 IMKB contra-angle.
Irrigation pump: 20-65 ml/min., adjustable
Classification: Class 1, Type B (EN 60601-1 and EN 60601-1-2 class B
BF applied equipment.
Mains voltage: 115/230V, 50-60 Hz
Mains connection: 1-phase with protective ground
Max. power consumption: 380 VA
Fuses: 2 pcs. T 3.15A (115V)
2 pcs. T 1.6AL (230VAC)
Replacement of fuse: Fuse carrier is removed and fuse is replaced.
Surroundings operational: +10 to +35 degrees Celsius.
30-70% air humidity. 70-106 kPa.
Surroundings -40 til +70 degrees Celsius.
Transport, storage: 10-98% air humidity. 50-96 kPa.
Manufacturer: XO CARE A/S
Usserød Mølle,
Håndværkersvinget 6
DK-2970 Hørsholm
Denmark
Tel: + 45 70 20 55 11
info@xo-care.com
www.xo-care.com
