Installation instructions
Installation instructions
Please note, that this installation manual was generalized attending to provide
you with the common indispensable information. Therefore it might cause from
product to product some irrelevant discrepancies, especially regarding some
depictions (e.g. installation accessories)
You can nd the detailed manual for your XOMAX product on our homepage:
www.xomax.de/download
1 Installation steps
1. xture accessories (if included)
1 x xation metal sheet
1 x bolt
1 x nut
1 x washer
2. installation frame *
3. dual-ended bolt (if included)
4. unit
5. bezel (if included)
* - Installation frame is already rmly
xed to the unit's housing by delivery
1
1 2 3 4 5
