6. Appendix
6.1. Technical Data
Working range 60mm travel of measuring gauge on different adjustable positions
Diameter range 10-200mm
Measuring system Digital gauge with 0.5μ resolution
Accuracy Digital gauge:+/-2,0μ
Repeat accuracy: 1μ
Total accuracy depending on lens geometry
Dimension(WxDxH) 300x460x650mm
Weight Approx. 30kg
Connections Power: 100-240V/50-60Hz
Compressed air 6 bar
Color Light grey RAL7035
