3.1.2. Adjustment oft he upper and lower measuring key button
Illustration 5: Adjusting the upper probe
1. Release the clamping
2. Adjust the measuring key
3. Lock the clamping
Illustration 6: Adjust the lower probe
1. Hold the lower probe
2. Release the probe
3. Adjust the lower probe
4. Lock the clamping
1;3
2
2;4
1
3
