2.2. Operation elements
Mituoyo digital gauge 543-564D
- Turn on and off
- Display for indication of measurements
- Adjustment Preset:
See chapter 5.1 or
operating manual measuring gauge 543-564D
Remote control for Mitutoyo digital gauge 543-564D
Manual chuck
centering the lens
Switch for the upper probe
UP / DOWN
Switch for the lower probe
UP / DOWN
