2. Product description
2.1. Configuration
Illustration 1: XONOX CT 200 exposition with inscription
1 Mitutoyo digital gauge 543-564D
2 Input valve (pneumatic)
3 Respective holder + gauge block 10mm
4 Lower probe
5 Manual chuck
6 Switch lower probe UP/DOWN
7 Switch upper probe UP/DOWN
8 Holding adapter for lenses
9 Upper probe
1
5
9
8
7
6
2
4
3
