Xray XB8E - Page 19

19
4. REAR SUSPENSION
353354-H
SHIM 3x9x7
902318
SH M3x18
902330
SH M3x30
960030
N M3
2x
L=R
7mm
NOTE
ORIENTA
TION
INITIAL SETTING
INITIAL SETTING
DETAIL
L=R
960030
N M3
903312
SFH M3x12
902314
SH M3x14
2x
2x
2x
4x
2x
2x
2x
2x
3x12mm
3x14mm
3x18mm
3x18mm
3x30mm
908318
SCH M3x18
