18
4. REAR SUSPENSION
CAMBER
980317
P 3x17
901504
SB M5x4
941318
BB 13x19x4
980263
P 2.5x13
940816
BB 8x16x5
353370
SHIM 3x9x1
353370
SHIM 3x9x2
960030
N M3
Before tightening the pivot pin locknut, ensure the rear upright
moves freely. If it DOES NOT move freely, lightly sand both
wheelbase shims and recheck for bind.
Shims for wheelbase
adjustment
DO NOT overtighten the self-locking nut.
Overtightening may result in suspension bind.
If the rear upright DOES NOT move freely, use a HUDY Arm Reamer to resize the hole.
ARM REAMER
1+1mm
2mm
INITIAL SETTING
(HUDY #107643)
2x
L=R
Check for free
movement.
DETAIL
DETAIL
RIGHT
THREAD
LEFT
THREAD
OIL
OIL
RIGHT THREAD
RIGHT THREAD
LEFT THREAD
LEFT THREAD
26.5mm 26.5mm
NOTE
ORIENTATION
NOTE ORIENTATION
➊
➋
➌
➏
➐
➑
➍
➎
8x16x5mm
3x17mm
2.5x13mm
13x19x4mm
To tighten the setscrew you can
also use the HUDY 17mm Wheel
Nut Tool #107570.
2.5mm
DETAIL
93mm SHORT CVD DRIVE SHAFT
2x
L=R
BOOK
SET-UP
DETAIL
Use tools to tighten as shown.
Special Tool for all turnbuckles & nuts (HUDY #181090)
or Turnbuckle Wrench 5mm (HUDY #181050).
Install the pivot balls with Professional
Multi-Tool (HUDY #183011).
2x
L=R
OFFSET WHEEL AXLES
#355250 0mm OPTION
#355251 +1mm OPTION
#355252 +2mm INCLUDED
NOTE ORIENTATION
Use HUDY Ball-Bearing Grease
#106220 - STANDARD
#106221 - BLUE
#106222 - RED
Graphite Grease
(HUDY #106210)
Follow the TECH TIP on page
5 for drive shaft pin servicing.
2x
2x
2x
2x 2x
4x
2x
2x
REAR UPRIGHTS
#353354 MEDIUM OPTION
#353354-H HARD INCLUDED
#353354-G GRAPHITE OPTION
#350908 ALU-SET OPTION
1
4 | 3 | 2 | 1
4
3
2
Drive shaft position
#355215
CVD ADJUSTABLE DRIVE AXLE - HUDY SPRING STEEL™
To Next Page
