45
More DROOP lower than 104-105mm
If more than 104-105mm front droop is used, certain set-up configurations may result in the upper arm contacting the steering bellcranks.
This will have limited impact on handling, but material can be removed from the bottom of the upper arm to avoid contact with the steering
assembly if using additional droop.
DIFF MAINTENANCE
REMOVE HARDWARE
- Gearbox Cover Upper Screws (2)
- Gearbox Cover Lower Screws (2)
- Shock Absorber Locknuts (2)
- Disconnect Anti-Roll Bar Linkage
Using a strong tool,
carefully pry up from
below anti-roll bar to
separate cover from
gearbox.
Strong Tool
REMOVING THE DIFFERENTIAL WHEN CAR IS ASSEMBLED
&
To Next Page
