Technische specificaties DVB-T2/T/C2/C Mode:
System Capabilities: Fully DVB compliant
LCD Screen: 5 inch TFT
Processor: Chipset : MB86H61
Flash Memory: 16MByte
DDRAM Memory: 2 x 1Gb
Tuner: GST_GCXU-00R
Frequency Range: 174~230MHz VHF
470~858MHz UHF
Input Impedance: 75Ω
Active Ant Power: 5V
Input Level Range: -20dBm~-85dBm
Demodulation: QPSK,8PSK,16QAM,
64QAM,256QAM
Bandwidth: 6/7/8MHz
FFT SIZE: 2K/4K/8K
Code Rate: 1/ 2, 2/3, 3/4, 5/6. 7/8
T/C2/C Mode:
Fully DVB compliant
5 inch TFT
Chipset : MB86H61
16MByte
2 x 1Gb
EDS-11670FNPVA
950~2150MHz
75Ω
13/18V
-20dBm~-85dBm
QPSK,8PSK
1 to 45
NA
1/2, 3/5, 2/3, 3/4, 4/5, 5/6,
8/9, 9/10
Physical Specification
Size (BxHxL): 233 x 135 x 50mm
Weight: 1,14 kg
Temperature: 0°C to + 40°C
Storage temperature: -40°C to + 65°C
Power supply
Li-oN Battery: 2700mAh*2
Supply voltage: 15Volt,2.5A
Charger: 175 - 250 V ~, 50/60 Hz
Panel connectors
Digital tuner input: F type, female
