Xterra FB360 User Manual

19
PARTS LIST
NO.
PART NUMBER
DESCRIPTION
QTY
01
9936001
Front support tube
1
02
9936002
Rear support tube
1
03
9936003
Seat support tube
1
04
9936004
Handlebar tube
1
05
9936005
Front stabilizer
1
06
9936006
Rear stabilizer
1
07
9936007
Seat
1
08 9936008 Computer 1
09L
9936009L
Pedal L
1
09R
9936009R
Pedal R
1
10
9936010
Adjustment knob M12
1
11
9936011
Lock pin φ8x70L
1
12 9936012 Screw Set 4
13
9936013
Curved washer φ8.3xφ22
6
14
9936014
Domed nut M8
5
15L
9936015L
Crank L
1
15R
9936015R
Crank R
1
16
9936016
Flat washer φ8.3xφ17.5
3
17
9936017
Nylon nut M8
5
18
9936018
Hand pulse wire
1
19
9936019
Middle sensor wire
1
20
9936020
Flat washer φ4.3xφ12
2
21 9936021 Sensor bracket 1
22
9936022
Allen bolt M8x15L & Flat washer
∅
25
2
23
9936023
End cap for handlebar
4
24
9936024
EVA pad
1
25
9936025
Hand pulse sensor
2
26 9936026 Foam grip for handlebar 2
27
9936027
Lower sensor wire
1
28
9936028
Screw M5x20L
1
29
9936029
Flat washer φ10.3xφ25
1
30
9936030
Self-tapping screw M4x10L
1
31 9936031 Self-tapping screw ST4.2x12L 6
32
9936032
Self-tapping screw ST4.2x20L
11
33
9936033
Magnet assembly
1
34
9936034
Axle for Main frame
1
35
9936035
Flat washer φ5.2xφ18
1
36 9936036 Pulley 1
37
9936037
Plastic washer φ6.5 xφ13
1
