7
STEP 1 FRONT STABILIZER AND REAR STABILIZER
1. Pull out the lock pin (11) from the front support tube (01) and adjust the front support tube (01) to the
correct position then insert lock pin (11) to secure the front support tube (01).
2. Attach the front stabilizer (05) to the front support tube (01), tighten with 2 curved washers (13) and 2
domed nuts (14).
3. Attach the rear stabilizer (06) to the rear support tube (02), tighten with 2 curved washers (13) and 2
domed nuts (14).
STEP 2 PEDALS
Pre-assembled on Main Frame:
1 Lock pin (#11)
Pre-assembled on Front & Rear
Stabilizer:
4 Curved washers (#13)
4 Domed nuts (#14)
To Next Page
