SB120 Recumbent Bike
SB120 Parts Checklist
NO. 01 NO. 02 NO. 03 NO. 04
NO. 05 NO. 06 NO. 07 NO. 08
NO. 24 NO. 25 NO. 26 NO. 28
NO. 29
PART NO. DESCRIPTION Q’TY
01 Main frame 1
02 Front post 1
03 Backrest support bracket 1
04 Front handlebar 1
05 Rear handlebar 1
06 Front stabilizer 1
07 Rear stabilizer 1
08 Adjusted bar 1
24 Console 1
25 Seat 1
26 Back cushion 1
28 Pedal (L) 1
29 Pedal (R) 1
