SB120 Recumbent Bike
5
SB120 Parts List
Part No. Serial No. Description Q’TY
01 SB120-RB1036-PART01 Main frame 1
02 SB120-RB1036-PART02 Front post 1
03 SB120-RB1036-PART03 Backrest support bracket 1
04 SB120-RB1036-PART04 Front handlebar 1
05 SB120-RB1036-PART05 Rear handlebar 1
06 SB120-RB1036-PART06 Front stabilizer φ50x1.2tx395L 1
07 SB120-RB1036-PART07 Rear stabilizer φ50x1.2tx490L 1
08 SB120-RB1036-PART08 Adjustable bar 16x2tx305L 1
09 SB120-RB1036-PART09 Connection axle φ12x95L 1
10 SB120-RB1036-PART10 Upper sensor wire 1
11 SB120-RB1036-PART11 Lower sensor wire 1
12 SB120-RB1036-PART12 Upper pulse sensor wire 1
13 SB120-RB1036-PART13 Pulse sensor wire 1
14 SB120-RB1036-PART14 Middle pulse sensor wire 1
15 SB120-RB1036-PART15 Carriage bolt M8x60L 4
16 SB120-RB1036-PART16 Allen screw M8x40L 2
17 SB120-RB1036-PART17 Allen screw M8x15L 4
18 SB120-RB1036-PART18 Allen bolt M8x35L 4
19 SB120-RB1036-PART19 Allen bolt M8x65L 2
20 SB120-RB1036-PART20 Allen bolt M6x20L 4
21 SB120-RB1036-PART21 Lower pulse sensor wire 1
22 SB120-RB1036-PART22 Crossed head self-tapping screw M4x10L 1
23 SB120-RB1036-PART23 Crossed head screw M5x10L 2
24 SB120-RB1036-PART24 Console 1
25 SB120-RB1036-PART25 Seat 1
26 SB120-RB1036-PART26 Back cushion 1
27 SB120-RB1036-PART27 Limited bracket JE099 1
28 SB120-RB1036-PART28 Pedal (L) JG-16B 1
29 SB120-RB1036-PART29 Pedal (R) JG-16B 1
30 SB120-RB1036-PART30 Domed nut M8x16t 4
31 SB120-RB1036-PART31 Nut M8x8t 2
32 SB120-RB1036-PART32 Allen screw M8x15L 4
33 SB120-RB1036-PART33 Curved washer φ8.5xφ20x1.5t 12
34 SB120-RB1036-PART34 Flat washer φ6.5xφ13x1.5t 2
35 SB120-RB1036-PART35 Crank w/ pulley 1
