6
SB120 Recumbent Bike
SB120 Parts List
36 SB120-RB1036-PART36 Sticker 1
37 SB120-RB1036-PART37 Crossed head self-tapping screw
ST4.2x12L
2
38 SB120-RB1036-PART38 Flange nut M10x1Px6t 2
39 SB120-RB1036-PART39 Crossed head self-tapping screw st4.2x20L 4
40 SB120-RB1036-PART40 Flat washer φ4.3xφ12x1t 2
41 SB120-RB1036-PART41 Sensor bracket 1
42 SB120-RB1036-PART42 Chain cover L 1
43 SB120-RB1036-PART43 Chain cover R 1
44 SB120-RB1036-PART44 Cover for crank JE437 2
45 SB120-RB1036-PART45 End cap for sliding seat 2
46 SB120-RB1036-PART46 End cap for front handlebar 4
47 SB120-RB1036-PART47 End cap for seat post 2
48 SB120-RB1036-PART48 End cap 1
49 SB120-RB1036-PART49 End cap 1
50 SB120-RB1036-PART50 End cap 1
51 SB120-RB1036-PART51 8-level tension knob 1
52 SB120-RB1036-PART52 Self-taping screw st4.2x8L 2
53 SB120-RB1036-PART53 Flat washer φ12.5xφ20x1.5 1
54 SB120-RB1036-PART54 Self-tapping screw st4.2x20L 8
55 SB120-RB1036-PART55 Foam grip for rear handlebar 22x28x560L 2
56 SB120-RB1036-PART56 Foam grip for front handlebar 22x28x150L 2
57 SB120-RB1036-PART57 End cap for rear stabilizer 2
58 SB120-RB1036-PART58 End cap for front stabilizer 2
59 SB120-RB1036-PART59 Belt 310 J5 1
60 SB120-RB1036-PART60 Non-slip plate 1
61 SB120-RB1036-PART61 Self-tapping screw ST3.2x12L 1
62 SB120-RB1036-PART62 Ball for adjusted bar 1
63 SB120-RB1036-PART63 Grommet 1
64 SB120-RB1036-PART64 Hand pulse sensor 2
65 SB120-RB1036-PART65 Adjusted iron plate 27Lx26Wx33Hx3.0t 1
66 SB120-RB1036-PART66 Flywheel assembly 1
67 SB120-RB1036-PART67 BB parts 1
68 SB120-RB1036-PART68 Flywheel adjustor φ18x55L 2
69 SB120-RB1036-PART69 Flywheel adjustor φ18x55L 1
70 SB120-RB1036-PART70 Crossed head M5x12L 1
71 SB120-RB1036-PART71 EVA pad 38Lx18Wx3t 1
72 SB120-RB1036-PART72 Multifunctional wrench 1
73 SB120-RB1036-PART73 Allen key 1
