6PEDALSANDBASECOVER

17
1
36
37
48
47
53
53
53
87
40
1.Theleftandrightpedals(37&36)aremarked“L”&“R”.Attach
thestrapstothepedals.Connecttherightpedal(36)tothe
crank(17)ontherighthandsideofthecycleasyousitonit.
Repeatfortheleftpedal(37).
Note:Therightpedalshouldbethreadedonclockwiseandtheleftpedal
oncounter‐clockwise.
2. Attachtheleftrearsupportcover(47)totheleftsideofthe
supporttube(40).Secureusingtwoselftappingscrews(53).
3.Attachtherightrearsupportcover(48)totherightsideofthe
supporttube(40).Secureusingthreeselftappingscrews(53).
Hardware Step 6
Preassembled on covers:
5 Self Tapping Screws (#53)
