SB150

ASSEMBLYINSTRUCTIONS

1FRONTSTABILIZER

2
3
4
5
1


1. Attachthefrontstabilizer(3)tothemainframe(1),securing
withtwoallenscrews(2),twospringwashers(4)andtwo
curvedwashers(5).
2
SUPPORTTUBEANDREARSTABILIZER

1
21
21
21
38
38
38
39
40
6
23
24
31
34
33

1.Connectmiddleextensionhandpulsewire(33)withrearextension
handpulsewire(34).Attachsupporttube(40)tomainframe(1),
andtightenwith6setsofallenscrew(21)andflatwasher(38).
Attachthelevelingpad(39)tothebottomofmainframe(1).
2. Attachrearstabilizer(6)tothesupporttube(40)andtighten
with2setsofcarriagebolt(23),curvedwasher(24)and
domednut(31).
Tip:AvoidpinchingtheExtensionWires
Hardware Step 2
Hardware Step1
2 Allen Screws (#2)
2 Curved Washers (#5)
2 Spring Washers (#4)
Hardware Step 1
6 Allen Screw (#21)
6 Flat Washers (#38)
2 Carriage Bolt (#23)
2 Curved Washers (#24)
2 Domed Nut (#31)
