DyacoCanadaInc2017
12
SB150
ASSEMBLYINSTRUCTIONS
5REARHANDLBARASSEMBLY
1
44
21
43
5
29
13
28
35
34
1.Attachbackcushion(44)totheseatsupportbracket(43).
Secureusingfourallenscrews(21).
2.Attachrearhandlebar(13)totheseatsupportbracket(43).
Secureusingtwocarriagebolts(28),twocurvedwashers(5)
andtwodomednuts(29).
3.Connectrearextensionhandpulsewire(34)tothehandpulse
wire(35).
Tip:AvoidpinchingthepulseWires
Hardware Step 5
4 Allen Screws (#21)
2 Carriage Bolts (#28)
2 Curved Washers (#5)
2 Domed Nuts (#29)
