Xterra SB150 - Seat Assembly

customerservice@dyaco.ca
DyacoCanadaInc2017

11

4SEATASSEMBLY

40
1
42
41
21
43
45
21
21
21
21
41



1. Inserttheslidingtube(41)intoseatsupportbracket(43).
Lineuptheholesandsecureslidingtube(41)withquick
releaseknob(42).
2. Attachseatcushion(45)totheseatsupportbracket(43).
Secureusingfourallenscrews(21).
3. Attachtheslidingtube(41)tothe
supporttube(40).Secure
usingeightallenscrews(21).








Hardware Step 4
12 Allen Screws (#21)
