Xterra SB4.5r User Manual

SB4.5r Fitness Bike
5
#80. 3/8”
Nyloc Nut
(4 pcs)
#71. 3/8” x 19mm
Flat Washer
(4 pcs)
#100. 3/8” x 3”
Hex Head Bolt
(4 pcs)
Hardware Step 2
#71. 3/8” x 19mm
Flat Washer
(6 pcs)
#102. 5/16” x 19mm
Curved Washer
(2 pcs)
#70. 5/16” x 18mm
Flat Washer
(4 pcs)
#101. 3/8” x 3/4”
Hex Head Bolt
(6 pcs)
#95. 5/16” x 3/4”
Button Head Socket Bolt
(6 pcs)
Hardware Step 3
